Poly280-60 Factory: Your Trusted Source For Premium Quality Products

POLY280-60

Model: GJS-P280-60 Arrange:6*10 Size:1640*992*35 Glass Type:3.2mm High transmittance coating Tempered glass Blackplane:White/Black Junction Box:Protection level IP68 Cable:PV special cable Number of Diodes:3 Wind/Snow Pressure:2400Pa/5400Pa Adapter:MC4 Product certification:IEC61215、IEC61730

Characteristic

High quality silicon wafer guarantee，high power component output and excellent cost performance advantage are ideal for customers; Buy high quality products at cheap prices; Better weak-light power generation performance; High end battery slicing technology, the series current is reduced,Reduce the internal loss of components,It is an ideal for projects in high heat areas; load bearing 5400Pa snow load and 2400Pa wind pressure; Automatic production line and Leading photovoltaic technology;

Performance Parameter

Peak power (Pmax):280W Maximum Power Voltage(Vmp):31.67V Maximum Power Current(Imp):8.85A Open Circuit Voltage(Voc):38.02V Short Circuit Current(Isc):9.37A Module Efficiency(%):17.2% Working Temperature:45℃±3 Maximum Voltage:1000V Battery Operating Temperature:25℃±3 Standard test conditions:Air quality AM1.5,Irradiance 1000W/㎡,Battery temperature

Optional configuration

Adapter:MC4 Cable length:Customizable (50cm/90cm/other) Backplane color:Black/White Aluminum frame:Black/White

Advantage

We guarantee high quality silicon wafer,high power component output and excellent cost performance advantage are ideal for customers; You can buy high quality products at cheap prices; The solar panels are better weak-light power generation performance; We have high end battery slicing technology,the series current is reduced,Reduce the internal loss of components,It is an ideal for projects in high heat areas; load bearing 5400Pa snow load and 2400Pa wind pressure; Automatic production line and Leading photovoltaic technology;

Details

Our solar panels have diodes in order to prevent current recoil and stabilize the current; The most suitable angle for solar panel mounting is the horizontal 45 °; Solar panels should be kept clean during normal use to ensure the surface is not blocked and extend their life
